INTEGRITY-PRO Joint Monitoring software is a bespoke database system specifically developed to plan, monitor, control and provide traceability of flanged joints and connections. The database calculation engine uses the Baseline Standard ASME PCC-1 2013 Appendix O Section O-4.1 and Appendix H Table H-1 to define the residual bolt load/stress, and is compared with tabled values in the SHELL ES/090 Rev 2 Specification. INTEGRITY-PRO runs on the standard Windows operating system and can be used as stand alone or networked. It has been adopted by major plant operators as an essential management system due to it’s simplicity and comprehensive covering of the plant and related maintenance. Offering data gathered from years of industry experience, Integrity-Pro can provide bolt tightening data including bolting patterns, torque and tensioning figures, procedures, techniques and recommended controlled bolting equipment. Based on the information entered, the Integrity-Pro software will analyse all of the data and produce a complete calculation sheet along with the required torque or tension figures to ensure an accurate and correctly bolted joint is achieved.
Integrity-Pro can also create a specific tightening procedure for each bolted joint, which can include specific information such as any special remarks all of which can be easily entered into the software by the user. It also includes basic information for standard flanges, wafer check valves, spade and spacers, and swivel flange assemblies.Integrity-Pro joint integrity database management system is used to support bolted joint inspection and maintenance and/or leak testing activities raising safety levels across the industry in which it applies.
